2) AISP-S 2.1 Programming and Development Board (For Atmel Controllers)
Some of the main features of the AISP-S 1.3 Board are listed below:
1) Easy programming of the flash with the serial port of computer.
2) On board power regulator and power on LED.
3) Wide power supply range from 8-15 Volts DC.
4) Protection Diode for reverse supply protection.
5) Use of same serial port for programming, transmitting and receiving.
6) Toggling between programming/execution modes with press of single switch eliminating the need for any complex changes
in the hardware.
7) A direct access to all the 4 ports viz. 32 I/O lines. No change in the port address.
8) 2x5 (8 port lines, 1 Vcc and 1 GND pin) IDC headers are provided on the ports for easy interfacing of the external
devices like matrix keyboard, ADC, DAC, 7 – Segment display, relays etc.
9) LEDs on port to test the bit pattern.
10) By default AT89C51RD2 is supplied with the Board which has an inbuilt flash memory of 64KB and inbuilt RAM of 1KB.
11) No special skills are required to operate the Board.
12) Hex file can be downloaded easily with the help of user friendly software Flash Magic.
13) Following is the list of ICs of ATMEL, supported by the board
AT89C51RB2, AT89C51RC2, AT89C51RD2, AT89C51ED2
The Sales Package contains
1) A Hardware Board
2) A serial cable (Approximately 1 meter long)
3) Compact Disc (CD) that contains User's Manual and Flip Software
3) APRG 1.1 Programmer for 89 Series ATMEL ICs
Some of the main features of the APRG 1.1 Board are listed below:
1) Easy programming of the IC with the serial port of computer.
2) On board power regulator and power on LED.
3) Wide power supply range from 12-15 Volts DC.
4) No special skills are required to operate the Board.
12) Hex file can be downloaded easily with the help of user friendly software EZUploader provided with the board.
5) Following is the list of ICs of ATMEL, supported by the board
89C51,89C52,89C55,89S51,89S52,89Cxx51
The Sales Package contains
1) A Hardware Board
2) A serial cable (Approximately 1 meter long)
3) Compact Disc (CD) that contains User's Manual and EZUploader Software
Student Projects and Projects for Hobbyists
1) 24 Hr. On-Off Timer with clock
2) 99 min. 59 sec count down timer
3) Intellegent code lock
4) Temperature controller with digital display
5) 8 Channel Quiz Monitor
6) Four digit digital stop watch.
7) Four digits Infrared object counter
8) Real time clock with LCD display, calender and alarm
9) Long range 3-stage FM transmitter
10) School/college bell timer
|
